Usually it is used for transfering the movement from working engine. Its hydraulic pump couples as turning side of engine.

If the turning side doesn’t determine correctly, it cannot work. It transfers 350 HP (257,6 KW). Hydraulic couplıng has two output couplıng.

Coupling one can be working sıngle or together with second coupling. Head coupling’s turning hoop must be equal to the driven hoop or must be smaller than the driven hoop. It can couple in place of head coupling which is on the body of

Weight : 290 kg.
Reduction rate : 1/1 (turning side is reverse the engine) It has two reductıon couplıng whıch ıs turnıng reverse accordıng to engıne .Pump assembly set accordıng to rotatıng dırectıon.
Hydraulic Working Pressure: 25 – 30 Atm.
Lubricating : 12 Lt
